17

LIEBERT NFINITY 20KVA PWR SUP

Mfg. Part: NB20S0712600 | CDW Part: 1282262 | UNSPSC: 39121011
$22,228.99Advertised Price
Lease Option ($665.09 /month) Lease Availability
Close

Have leasing questions? Let us know how can we help.

Note: Leasing is available to businesses only. Leasing is not available to individuals.
800.800.4239
Mon-Fri 7am-7:30pm CT
Availability:Call
Call for availability
  • UPS
  • External
  • 20000 VA power capacity
  • 12 min battery run time (up to)
  • 14 kW power provided
  • AC 120/208 V
  • 2 years warranty
View More

Recommended Services

Product Overview
Main Features
  • UPS
  • External
  • 20000 VA power capacity
  • 12 min battery run time (up to)
  • 14 kW power provided
  • AC 120/208 V
  • 2 years warranty
The Nfinity power system is a scalable 4 to 16 kVA or 12 to 20 kVA UPS, designed with N+x parallel redundancy to provide a fault-tolerant network of power protection. Its modular design was devised to provide easy scalability to users as their power demands grow. Configurations can be cost-effectively upgraded without re-investing in a new system or installation.

Nfinity's patent pending frame design houses all of the modular system components, including 4 kVA power modules, battery modules and system control modules. By simply installing additional power or battery modules, you can expand your current system, extend your backup runtime or add redundancy. Hot-swap capability makes it easy to add or replace modules.

The system's fault-tolerant design enables the intelligent power and battery modules to take themselves off-line if there is a problem - without compromising system integrity. Self-diagnostic capabilities simplify maintenance and troubleshooting. Nfinity also offers redundancy in its unique paired system controls, internal and external bypass, and monitoring options.

Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Battery
Enclosure Type: Plug-in module
Load Type: At full load
Run Time (Up To): 12 min
Voltage Provided: 120 V

Interface Provided
Connector Type: 9 pin D-Sub (DB-9)
Qty: 2
Type: Management (RS-232)

Service
Support Details Full Contract Period: 2 years
Support Details Service Included: Parts and labor
Support Details Type: Limited warranty

Environmental Parameters
Humidity Range Operating: 0 - 95%
Max Operating Temperature: 104 °F
Min Operating Temperature: 32 °F
Sound Emission: 62 dBA

Header
Brand: Liebert
Compatibility: PC
Manufacturer: Liebert
Packaged Quantity: 1
Product Line: Liebert Nfinity

Miscellaneous
Color: Black , Charcoal gray
Color Category: Black , Gray
Compliant Standards: cUL , FCC Class A certified , UL 1778
Features: Audible alarm , LCD display , LED display , Wheels

Power Device
Form Factor: External
Frequency Provided: 60 Hz
Frequency Required: 60 Hz
Load Rating: Large LAN / minicomputer
Power Capacity (VA): 20000 VA
Power Provided: 14 kW
UPS Output Waveform: Sinewave
UPS Technology: On-line
Voltage Provided: AC 120/208 V
Voltage Provided Margin: ± 3%
Voltage Required: AC 208 V

Service & Support
Type: 2 years warranty

Slot Provided
Free Qty: 5
Total Qty: 6
Type: Expansion slot

Slot Required
Type: None

Dimensions & Weight
Depth: 28 in
Height: 54 in
Width: 20 in

Chassis
Installed Devices Modules Qty: 12
Supported Devices Modules Qty: 12

General
Product Type: UPS
Subcategory: UPS

Run Time Details
Load Type: Full load
Run Time (Up To): 12

UPS
Batteries Qty: 7
Battery Technology: Lead acid
