Sophos UTM 220 - security appliance

Mfg. Part: ASGN02200APUS | CDW Part: 2787395 | UNSPSC: 43222501
Request PricingCall

This item was discontinued on October 24, 2013.

Sales Assistance

800.800.4239 Mon-Fri 7am-7:30pm CT

Answer within 24 hours.


Have leasing questions? Let us know how can we help.

Note: Leasing is available to businesses only. Leasing is not available to individuals.
Mon-Fri 7am-7:30pm CT
  • Security appliance
  • 8 ports
  • 10Mb LAN
  • 100Mb LAN
  • Gigabit LAN
  • 1U
  • rack-mountable
View More
Product Overview
Main Features
  • Security appliance
  • 8 ports
  • 10Mb LAN
  • 100Mb LAN
  • Gigabit LAN
  • 1U
  • rack-mountable
The Sophos UTM 220 provides easy-to-use security for users. The rack-mountable device comes equipped with eight separately manageable network ports. It can be deployed within enterprise-class scenarios, including load-balanced and fail-over connections - without complicated configuration and maintenance. Based on Intel-compatible technology, the UTM appliance provides high reliability and performance. And it can be extended with additional security measures, protecting your network - and your investment - for many years.

Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Chassis Built-in Devices: Status LCD

Type: Connection / user qty
Value: Up to 300

Type: Concurrent connections
Value: 300000

Dimensions & Weight
Depth: 14.4 in
Height: 1.7 in
Weight: 12.1 lbs
Width: 16.8 in

Environmental Parameters
Humidity Range Operating: 10 - 90% (non-condensing)
Max Operating Temperature: 104 °F
Min Operating Temperature: 32 °F

Hard Drive
Installed Qty: 1
Type: HDD

Brand: Sophos
Compatibility: PC
Country Kits: United States
Manufacturer: Sophos
Model: UTM 220
Packaged Quantity: 1
Product Line: Sophos

Interface Provided
Connector Type: RJ-45
Qty: 1
Type: RS-232

Type: VGA

Connector Type: Type A
Qty: 2
Type: USB

Qty: 8
Type: 1000Base-T

Compliant Standards: C-Tick , CB , FCC Class A certified , ICSA Firewall certified , UL , VCCI
Height (Rack Units): 1

Connectivity Technology: Wired
Data Link Protocol: Ethernet , Fast Ethernet , Gigabit Ethernet
Features: Anti-malware protection , Anti-spam protection , Antivirus analysis , DMZ port , DoS attack prevention , Firewall protection , Intrusion Prevention System (IPS) , NAT support , URL filtering , VPN support
Form Factor: Rack-mountable
Ports Qty: 8
Status Indicators: HDD activity , Power
Type: Security appliance

Type: Firewall throughput
Value: 3 Gbps

Type: VPN throughput
Value: 480 Mpps

Type: Intrusion prevention throughput
Value: 750 Mbps

Type: Antivirus throughput
Value: 165 Mbps

Type: Unified Threat Management (UTM) throughput
Value: 95 Mpps

Type: Email routing
Value: 400000 messages per hour

Power Device
Frequency Required: 50/60 Hz
Nominal Voltage: AC 120/230 V
Power Provided: 200 Watt
Type: Internal power supply

Storage Hard Drive
Capacity: 160 GB
