All Categories  > Computer Accessories  > Digitizer Tablets/Stylus  > Interlink Electronics DuraPoint pointing stick
Interlink Electronics DuraPoint pointing stick

Interlink Electronics DuraPoint pointing stick

Mfg. Part: VP2501  |  CDW Part: 578951  |  UNSPSC: 43211708
Log On to Email this Page or
Add to Favorites.




Pointing stick - 2 button(s) - wired - OEM
Main Features
Qty
$179.99
Advertised Price
$39.99
Advertised Price
Recommended Warranty: 2 Extra Years Replacement Extended Warranty $101-$200  |  See all warranties

Availability:
Availability
Call for availability.
Call
Product Overview
Technical Specs
Warranties and Services
Product Overview Interlink Electronics DuraPoint pointing stick
Main Features
  • Pointing stick
  • 2 button(s)
  • wired
  • OEM
Made of stainless steel with industrial-gauge rubber "mouse" buttons, DuraPoint is the world's toughest mouse! When properly mounted, the OEM "faceplate" version is NEMA rated and environmentally sealed - leaving no open areas to collect moisture, grime or dust. DuraPoint has no moving parts and is maintenance-free. From process-control centers to hospital operating rooms, DuraPoint survives where industrial trackballs and mice fail. Spill on it, smash it, soak it, drop it, bang it, even drive a truck over it: DuraPoint is indestructible.

DuraPoint was introduced by Interlink Electronics in 1993. Since then it has survived every tough situation imaginable, including a five-story drop during testing by MaxiData in Sweden, and being run-over by an 18-wheel semi-truck in California. What makes DuraPoint so tough? It combines Interlink Electronics' proprietary VersaPoint Pointing Technology with the highest quality product design, components, and construction.

DuraPoint's construction includes a thick stainless steel case that is resistant to the jolts and impacts common to manufacturing, industrial, and field computing applications. Mounted underneath and projecting up through its bezeled steel top is DuraPoint's interactive mouse button pad.

Made of industrial-gauge rubber, this pad, with its circular mouse button and parallel click actuators, delivers extremely fine cursor control and mouse click button support, yet is rugged enough to be environmentally sealed when installed, making the DuraPoint impervious to liquids, gases, dirt, dust and grime (DuraPoint is NEMA 4X, 12 and 13 rated).

Positioned directly beneath the mouse button pad is Interlink Electronics' patented Force Sensing Resistor (FSR). Protected by the case above and supported by a stainless steel plate, this four-zone sensor translates pressure from the mouse control button into signals that, when processed through a micro-controller, drive cursor direction and speed. The result: liquid-smooth 360-degree cursor control - all with the mild pressure of a fingertip. A light touch moves the cursor at a precise crawl, while heavy pressure speeds it across the screen.

DuraPoint's micro-controller and electronics are mounted to the underside of the steel plate supporting the pointing sensor. After circuit board installation, the entire inside of the unit is shot with a silicone potting material to permanently seal the device. Finally, rubber feet are added using bolt threads, enabling the DuraPoint to be used as a freestanding device or to be installed onto control panels and test equipment. Throw in a heavy-duty sealed connector cord, and you have what has proven itself to be the world's toughest computer mouse!
Technical Specifications Interlink Electronics DuraPoint pointing stick
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Environmental Parameters
Max Operating Temperature: 140 °F
Min Operating Temperature: 32 °F
Vibration Tolerance Operating: 0.5 G @ 5-500 Hz
Header
Compatibility: PC
Manufacturer: Interlink Electronics
Packaged Quantity: 1
Product Line: Interlink Electronics DuraPoint
Input Device
Buttons Qty: 2
Connectivity Technology: Wired
Form Factor: External
Type: Pointing stick
Interface Required
Type: Mouse
Miscellaneous
Package Type: OEM
Power Device
Type: None
Service
Support Details Full Contract Period: Lifetime
Support Details Type: Limited warranty
System Requirements
Min Operating System: IBM OS/2 , Microsoft DOS , Microsoft Windows 3.x/95/98 , Microsoft Windows NT , UNIX
Dimensions & Weight
Depth: 5 in
Height: 1 in
Width: 4.3 in
Service & Support
Type: Limited lifetime warranty
