Adaptec RAID 1220SA - storage controller (RAID) - SATA-300 - PCI Express x1

Adaptec RAID 1220SA - storage controller (RAID) - SATA-300 - PCI Express x1

Mfg. Part: 2232100-R  |  CDW Part: 1109601  |  UNSPSC: 43201557
Log On to Email this Page or
Add to Favorites.




Storage controller (RAID) - 2 Channel - SATA-300 low profile - 300 MBps - RAID 0, 1, JBOD - PCI Express x1
Main Features
Qty
$61.96
Advertised Price
Availability:
Availability
In stock and ready for shipment. Ships same day if ordered before 4pm CT.
In Stock
Product Overview
Technical Specs
Product Overview Adaptec RAID 1220SA - storage controller (RAID) - SATA-300 - PCI Express x1
Main Features
  • Storage controller (RAID)
  • 2 Channel
  • SATA-300 low profile
  • 300 MBps
  • RAID 0
  • 1
  • JBOD
  • PCI Express x1
The Adaptec RAID 1220SA card is a two-port, PCI Express x1 controller featuring Adaptec HostRAID - an integrated RAID technology that maximizes system performance and uptime. The Adaptec 1220SA supports up to two 3Gb/s Serial ATA drives, Native Command Queuing, and offers RAID levels 0, 1, and JBOD (individual drive). The Adaptec 48-bit logical block addressing (LBA) support enables use of disk drives exceeding 137 GB in capacity.
Technical Specifications Adaptec RAID 1220SA - storage controller (RAID) - SATA-300 - PCI Express x1
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Bay Provided
Type: None
Bay Required
Type: None
Cable
Connectivity Details Length: 3.3 ft
Connectivity Details Type: Serial ATA cable
Cables (Details)
Included Qty: 2
Environmental Parameters
Max Operating Temperature: 131 °F
Min Operating Temperature: 32 °F
Header
Compatibility: PC , Unix
Manufacturer: Adaptec
Model: 1220SA
Packaged Quantity: 1
Product Line: Adaptec RAID
Interface Provided
Connector Location: Internal
Connector Type: 7 pin Serial ATA
Interface: Serial ATA-300
Qty: 2
Type: Storage
Interface Required
Type: None
Miscellaneous
Compliant Standards: RoHS
Microsoft Certification: Works with Windows Vista
Product Type (CG): Storage controller (RAID)
Power Device
Type: None
Service
Support Details Full Contract Period: 3 years
Support Details Type: Limited warranty
Slot Provided
Type: None
Slot Required
Form Factor: Low-profile
Total Qty: 1
Type: PCI Express x1
Software
Type: Adaptec Storage Manager , Drivers & Utilities
Storage Controller
Channel Qty: 2
Controller Interface Type: Serial ATA-300
Data Transfer Rate: 300 MBps
Form Factor: Plug-in card
Interface Type: PCI Express x1
Low Profile: Low profile
Max Storage Devices Qty: 2
RAID Level: JBOD , RAID 0 , RAID 1
Supported Devices: Disk array (RAID) , Hard drive
System Requirements
Min Operating System: Microsoft Windows 2000 , Microsoft Windows Server 2003 , Microsoft Windows XP , Novell NetWare 6.5 , Red Hat Linux , SuSe Linux
Dimensions & Weight
Depth: 3.3 in
Height: 2.5 in
Service & Support
Type: 3 years warranty
