Iomega StorCenter Pro NAS 150d/1TB - NAS server

Iomega StorCenter Pro NAS 150d/1TB - NAS server

Mfg. Part: 33610  |  CDW Part: 1106903  |  UNSPSC: 43211501
Log On to Email this Page or
Add to Favorites.




NAS - 1 TB - Serial ATA-300 - HD 250 GB x 4 - RAID 0, 1, 5, JBOD, 0+1 - Gigabit Ethernet
Main Features
Qty
$734.99
Advertised Price
Lease Option
Leasing
Please see cdw.com/leasing for more information.
($23.95 /month)
$122.99
Advertised Price
Recommended Warranty: Iomega REV Rapid Response Silver Service Plan - extended service agreement  |  See all warranties

Availability:
Availability
Product ships in 1-3 business days from CDW. To arrange for same day drop shipping from our supplier, contact your account manager by 2pm CT.
1-3 days
Product Overview
Technical Specs
Accessories
Warranties and Services

Compatible Accessories for Iomega StorCenter Pro NAS 150d/1TB - NAS server

Product Overview Availability Advertised Price
CDW 12 Hour Burn-in Diagnostics
This offering is for a Burn-in service for 12 hours running a diagnostic program to test basic functionality on a s ... more
Availability
Call for availability.
Call
$21.99
Qty
BIOS/Firmware Update
Installation of latest firmware and BIOS revisions by certified CDW technicians.
Availability
Call for availability.
Call
$24.99
Qty
Product Overview Iomega StorCenter Pro NAS 150d/1TB - NAS server
Main Features
  • NAS
  • 1 TB
  • Serial ATA-300
  • HD 250 GB x 4
  • RAID 0
  • 1
  • 5
  • JBOD
  • 0+1
  • Gigabit Ethernet
The Iomega StorCenter Pro NAS 150d 1TB Server offers cost-effective, powerful network storage for any home or small office network. This high performance drive offers fast data throughput and time to data; RAID technology for ultimate protection and print server capability allowing users to manage up to 4 printers on the network. It integrates easily with your existing infrastructure and provides you with expanded storage, file sharing and back up for all your critical data.
Technical Specifications Iomega StorCenter Pro NAS 150d/1TB - NAS server
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Bay Provided
Free Qty: 0
Total Qty: 4
Type: Hot-swap
Bay Required
Total Qty: 0
Environmental Parameters
Humidity Range Operating: 8 - 85%
Max Operating Temperature: 95 °F
Min Operating Temperature: 50 °F
Header
Compatibility: Mac , PC
Manufacturer: Iomega
Model: 150d/1TB
Packaged Quantity: 1
Product Line: Iomega StorCenter Pro NAS
Interface Provided
Connector Type: RJ-45
Interface (Storage): Ethernet 10Base-T/100Base-TX/1000Base-T
Qty: 1
Connector Type: 4 pin USB Type A
Interface (Storage): Hi-Speed USB
Qty: 4
Miscellaneous
Compliant Standards: C-Tick , CE , cUL , FCC Class B certified , ICES-003 , TUV , UL , VCCI
Networking
Compliant Standards: IEEE 802.3 , IEEE 802.3u
Data Link Protocol: Ethernet , Fast Ethernet , Gigabit Ethernet
Form Factor: Integrated
Host Connectivity (for SD): Gigabit Ethernet
Network Services Compatibility: DHCP , Microsoft Active Directory (AD)
Network Transport Protocol: AppleTalk , IPX/SPX , TCP/IP
Type: Network adapter
Optical Storage (2nd)
Type: None
Power Device
Form Factor: Internal
Frequency Required: 50/60 Hz
Nominal Voltage: AC 120/230 V
Power Provided: 300 Watt
Type: Power supply
Processor
Clock Speed: 400 MHz
Installed Qty: 1
Service
Support Details Full Contract Period: 2 years
Support Details Type: Limited warranty
Service & Support
Type: 2 years warranty
Slot Provided
Type: None
Software
Type: Drivers & Utilities , EMC Dantz Retrospect Express Backup
Storage
Total Storage Capacity: 1 TB
Type: NAS server
Storage Controller
Controller Interface Type: Serial ATA-300
Data Transfer Rate: 300 MBps
Form Factor: Integrated
Installed Qty: 1
RAID Level: JBOD , RAID 0 , RAID 0+1 , RAID 1 , RAID 5
Supported Devices: Disk array (RAID) , Hard drive
Type: RAID
Storage Hard Drive
Buffer Size: 8 MB
Capacity: 250 GB
Installed Qty: 4
Interface Type: Serial ATA-300
Spindle Speed: 7200 rpm
Type: Hot-swap
Storage Hard Drive (2nd)
Type: None
Storage Removable
Type: None
System Requirements
Min Operating System: Apple MacOS X 10.2.7 or later , Debian Linux 3.0 , Mandrake Linux 10.0 , Microsoft Windows 2000 Professional / XP Professional , Microsoft Windows XP Home Edition , Red Hat Fedora Core 3 , Red Hat Linux 9
Dimensions & Weight
Depth: 11.5 in
Height: 10.4 in
Weight: 22 lbs
Width: 7.1 in
RAM
Installed Size: 128 MB
Type: DRAM
Cabinet (Chassis)
Installed Devices Modules Qty: 4
Supported Devices Modules Qty: 4
Optical Storage
Type: None
