IOGEAR 4 Port USB DVI KVM With Audio/Peripheral Sharing/Cables

IOGEAR 4 Port USB DVI KVM With Audio/Peripheral Sharing/Cables

Mfg. Part: GCS1764  |  CDW Part: 786406  |  UNSPSC: 43211604
This product was discontinued as of Monday, January 04, 2010. Call for availability.
Log On to Email this Page or
Add to Favorites.




4-Port USB DVI KVM With Audio/Peripheral Sharing/Cables
Main Features
Product Overview
Technical Specs
Accessories
Warranties and Services
Product Overview
Main Features
  • 4-Port USB DVI KVM With Audio/Peripheral Sharing/Cables
The IOGEAR DVI KVMP Switch GCS1764 charts a revolutionary new direction in KVM switch functionality by combining a 4-port USB KVM switch with USB peripheral sharing capability at the same time as it provides an interface for a digital monitor (DVI).

As a KVM switch, it allows users to access four computers from a single USB keyboard, USB mouse, and monitor, and any peripherals such as printers and scanners.

The GCS1764's independent (asynchronous) switching feature, allows the KVM focus to be on one computer while the USB peripheral focus is on another. This eliminates the need to purchase a separate USB hub as well as the need to purchase separate stand-alone peripheral sharers - such as printer servers, modem splitters, etc.

The GCS1764 further improves on previous designs with DVI (Digital Video Interface) connectors, and the transfer of keyboard and mouse data to the computers via a fast, reliable USB connection. DVI supports both digital input (flat panel displays, data projectors, plasma displays, digital TVs and set-top boxes) and analog video input (traditional monitors and TVs).


Features:
Dual function KVMP-USB switch
One console controls 4 computers
Independent (asynchronous) switching of KVM and peripheral USB/Audio ports
Fully compliant with the USB 1.1 specification - supports transfer rates of up to 12Mbps
DVI digital and analog monitor support - fully compliant with the DVI specifications
Computer selection via front panel switches and hotkeys
LED display for easy status monitoring
Auto Scan Mode for monitoring all computers
Complete keyboard emulation for error free booting
Superior Video quality - 1600 x 1200; DDC2B
Easy installation
Hot pluggable - add or remove computers for maintenance without powering down the switch
Supports Windows and Mac host systems

Requirements:
Console:
A DVI Monitor
A USB style mouse
A USB style keyboard
Microphone and speakers (optional)

Computers:
A DVI port (The quality of the display is affected by the quality of the DVI display card. For best results, we recommend you purchase a high quality product).
Type A USB port
Audio ports (optional)
Windows 98, 98SE, ME, 2000, XP
Mac OS 8.6 or greater

Cables:
Only IOGEAR Custom cable sets specifically designed to work with this switch may be used to link to the computers. Four cable sets are provided with this package.

Package content:
1 x GCS1764 KVMP switch
4 x 6' custom cables
1 x Firmware upgrade cable
1 x Power Adapter
1 x User Manual
1 x Quick Start Guide
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Cables (Details)
Form Factor: External
Included Qty: 1
Included Qty: 4
Service & Support
Type: 3 years warranty
Bay Required
Type: None
Cable
Connectivity Details Type: Data cable
Connectivity Details Length: 6 ft
Connectivity Details Type: Keyboard / mouse / video cable kit
Environmental Parameters
Max Operating Temperature: 122 °F
Min Operating Temperature: 32 °F
Header
Compatibility: Mac , PC , Unix
Manufacturer: iogear
Model: DVI KVMP Switch GCS1764
Packaged Quantity: 1
Product Line: IOGEAR MiniView
Interface Provided
Connector Type: Mini-phone stereo 3.5 mm
Interface: Line-out
Qty: 4
Type: Audio
Connector Type: Mini-phone 3.5 mm
Interface: Input
Type: Microphone
Connector Type: 29 pin combined DVI
Interface: DVI-Analog/Digital
Type: Display / video
Connector Type: 4 pin USB Type B
Type: Keyboard / mouse
Interface Required
Connector Type: 4 pin USB Type A
Total Qty: 1
Type: Keyboard
Type: Mouse
Connector Type: Mini-phone 3.5 mm
Interface: Input
Type: Microphone
Connector Type: Mini-phone stereo 3.5 mm
Interface: Line-out
Type: Audio
Connector Type: 29 pin combined DVI
Interface: DVI-Analog/Digital
Type: Display / video
KVM
Keyboard Mouse Interface: USB
KVM Local Users Qty: 1 local user
KVM Max Supported Video Resolution: 1920 x 1200
Miscellaneous
Compliant Standards: DDC-2B
Networking
Connectivity Technology: Wired
Form Factor: External
Ports Qty: 4
Subcategory (FE): KVM
Type: KVM / audio switch
Power Device
Form Factor: External
Type: Power adapter
Service
Support Details Full Contract Period: 3 years
Support Details Type: Limited warranty
Slot Provided
Type: None
Slot Required
Type: None
System Requirements
Min Operating System: Apple MacOS 8.6 or later , Linux , Microsoft Windows 2000 , Microsoft Windows 98 , Microsoft Windows 98 Second Edition , Microsoft Windows Millennium Edition , Microsoft Windows XP , UNIX
Dimensions & Weight
Depth: 2.9 in
Height: 1.7 in
Weight: 2.2 lbs
Width: 10.2 in
