Proview PL 456S

Proview PL 456S

Mfg. Part: PL456S  |  CDW Part: 567661  |  UNSPSC: 43211902
This product was discontinued as of Friday, April 01, 2005. Call for availability.
Log On to Email this Page or
Add to Favorites.




14" active-matrix LCD, Analog, Silver
Main Features
Product Overview
Technical Specs
Product Overview
Main Features
  • 14" active-matrix LCD
  • Analog
  • Silver
For those who desire style combined with quality. The sleek ultra-thin metallic-on-black design will deliver high quality and reliability.

PL456S is specially designed for home office and business, delivers bright, flicker free, high contrast ratio. DDC1/DDC2B allows communication between the monitor and PC system for optimal video configuration.
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Display (Projector)
Controls Adjustments: Brightness , Contrast , H/V position , Phase
Diagonal Size: 14 in
Display Screen Coating: Anti-reflective
Dot Pitch Pixel Pitch: 0.297 mm
Form Factor: Desktop
Image Contrast Ratio: 300:1
Image Max H-View Angle: 90
Image Max V-View Angle: 40
Interface: VGA (HD-15)
Max H-Sync Rate: 60 kHz
Max Resolution: 1024 x 768
Max V-Sync Rate: 75 Hz
Response Time: 50 ms
Technology: TFT active matrix
Type: LCD display
V-Sync Rate at Max Res.: 75 Hz
Video Bandwidth: 80 MHz
Viewable Size: 14 in
Display
Projector Image Brightness: 150 cd/m2
Interface Provided
Connector Type: 15 pin HD D-Sub (HD-15)
Interface (Output): VGA
Qty: 1
Video Input
Analog Video Signal: RGB
Audio Output
Type: None
Audio Input
Type: None
Dimensions & Weight
Depth: 4.9 in
Height: 12 in
Weight: 34.6 lbs
Width: 12.4 in
Environmental Parameters
Humidity Range Operating: 20 - 80%
Max Operating Temperature: 95 °F
Min Operating Temperature: 41 °F
Header
Compatibility: Mac , PC
Manufacturer: Proview Monitors
Model: 456S
Packaged Quantity: 1
Product Line: Proview PL
Miscellaneous
Compliant Standards: BSMI , C-Tick , CE , cUL , DDC-1 , DDC-2B , Energy 2000 , EPA Energy Star , FCC Class B certified , TUV , TUV GS , UL , VCCI , VESA DPMS
Power Device
Frequency Required: 50/60 Hz
Nominal Voltage: AC 120/230 V
Power Consumption Operational: 35 Watt
Power Consumption Stand by Sleep: 3 Watt
Type: Power adapter
Video Output
Type: None
