APC MasterSwitch VM, Zero U, 16A 208&230V

APC MasterSwitch VM, Zero U, 16A 208&230V

Mfg. Part: AP9229  |  CDW Part: 439988  |  UNSPSC: 39121017
This product was discontinued as of Wednesday, February 01, 2006. Call for availability.
Log On to Email this Page or
Add to Favorites.




16A, 8 IEC 320 C13 outlet remote power distribution unit
Main Features
Product Overview
Technical Specs
Warranties and Services
Product Overview APC MasterSwitch VM, Zero U, 16A 208&230V
Main Features
  • 16A
  • 8 IEC 320 C13 outlet remote power distribution unit
Advanced, remote power distribution and control for network administrators, Co-location facilities, ISPs, and applications where remote control of outlets is required Features:
Alarm Thresholds
Cascade (Daisy-Chain) Capabilities
Defineable Outlet Control
Hardwire Capabilities
Multiple User Support
Optional Controller for Web/SNMP/Telnet Management Sold Separately
Power-up Sequencing
Remote Current Monitoring
Single-Phase Power Input
Synchronization Sets
Telnet Control
Universal Power Supply
Zero U Rack Mounting Abilities

Includes:
10 ft RJ11 Cable
CD with software
Rack Mounting Brackets
User Manual
Technical Specifications APC MasterSwitch VM, Zero U, 16A 208&230V
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Cabinet (Chassis)
Type: Proprietary cabinet
Cables (Details)
Form Factor: External
Included Qty: 1
Power Supply
Device Compliant Standards: CSA , UL , UL 1950
Device Output Connector Type: Power IEC 320 EN 60320 C13
Battery
Type: None
Cable
Connectivity Details Length: 10 ft
Connectivity Details Type: Phone cable
Connectivity Details Length: 8 ft
Connectivity Details Type: Power cable
Service
Support Details Full Contract Period: 2 years
Support Details Service Included: Parts and labor
Support Details Type: Limited warranty
Environmental Parameters
Humidity Range Operating: 0 - 95%
Humidity Range Storage: 0 - 95%
Max Operating Temperature: 113 °F
Max Storage Temperature: 149 °F
Min Operating Temperature: 32 °F
Min Storage Temperature: 5 °F
Header
Compatibility: PC
Manufacturer: APC
Packaged Quantity: 1
Product Line: APC MasterSwitch
Miscellaneous
Color: Beige
Compliant Standards: C-Tick , CSA , FCC Class A certified , UL , VCCI
Rack Mounting Kit: Included
Rack Size: 19"
Networking
Type: None
Power Device
Form Factor (AG): Rack-mountable
Frequency Required: 50/60 Hz
Input Connector Qty: 1
Input Connector Type: Power IEC 320 EN 60320 C20
Input Voltage Range: AC 90 - 250 V
Output Connector Qty: 8
Type: Power distribution strip
Voltage Required: AC 208/230 V
Service & Support
Type: 2 years warranty
Slot Provided
Type: None
Slot Required
Type: None
Software
Type: Drivers & Utilities
System Requirements
Peripheral Interface Devices: CD-ROM
Dimensions & Weight
Depth: 1.8 in
Height: 46.5 in
Weight: 7.1 lbs
Width: 1.8 in
