All Categories  > Data Storage Products  > RAID Controllers  > LSI SAS3442E-R - storage controller (RAID) - SATA-300 / SAS - PCI Exp
LSI SAS3442E-R - storage controller (RAID) - SATA-300 / SAS - PCI Exp

LSI SAS3442E-R - storage controller (RAID) - SATA-300 / SAS - PCI Exp

Mfg. Part: LSI00167  |  CDW Part: 1385491  |  UNSPSC: 43201557
Log On to Email this Page or
Add to Favorites.




R - Storage controller (RAID) - 8 Channel - SATA-300 / SAS low profile - 300 MBps - RAID 0, 1, 1E, 10E - PCI Express x8
Main Features
Qty
$251.99
Advertised Price
Availability:
Availability
Call for availability.
Call
Product Overview
Technical Specs
Accessories

Compatible Accessories for LSI SAS3442E-R - storage controller (RAID) - SATA-300 / SAS - PCI Exp

Product Overview Availability Advertised Price
Tripp Lite External 1m SAS Cable - 4 Lane SFF-8088 to SFF-8470
Serial Attached SCSI (SAS) external cable - 4-Lane - 26 pin 4x Shielded Mini MultiLane SAS (SFF-8088) - 4x InfiniBa ... more
Availability
In stock and ready for shipment. Ships same day if ordered before 4pm CT.
In Stock
$109.99
Qty
Tripp Lite 18in Internal SAS Cable Mini SAS SFF-8087/SFF-8484
18 in. Internal SAS Cable, Mini-SAS SFF-8087 to SFF-8484
Availability
Call for availability.
Call
$39.99
Qty
Tripp Lite 3ft Internal SAS Cable Mini SAS SFF-8087/SFF-8484
3 ft. Internal SAS Cable, Mini-SAS SFF-8087 to SFF-8484
Availability
In stock and ready for shipment. Ships same day if ordered before 4pm CT.
In Stock
$44.99
Qty
Product Overview
Main Features
  • R
  • Storage controller (RAID)
  • 8 Channel
  • SATA-300 / SAS low profile
  • 300 MBps
  • RAID 0
  • 1
  • 1E
  • 10E
  • PCI Express x8
The LSI SAS3442E-R four-port internal/four-port external SAS PCI Express storage adapter provides 300 MB/s bandwidth on each port for combined throughput of up to 2.4 GB/s. The storage adapter supports multi-volume OS independent Integrated RAID 0, 1, 1E and 10E without the need for special drivers. The SAS3442E-R features PCI Express connectivity, removing the host bus bottleneck from the parallel PCI busses.

multilingual
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Bay Provided
Type: None
Bay Required
Type: None
Environmental Parameters
Humidity Range Operating: 5 - 95%
Max Operating Temperature: 140 °F
Min Operating Temperature: 32 °F
Header
Compatibility: PC , Unix
Manufacturer: LSI Logic
Model: SAS3442E-R
Packaged Quantity: 1
Product Line: LSI
Interface Provided
Connector Location: Internal
Connector Type: 32 pin 4i MultiLane SAS (SFF-8484)
Interface: Serial ATA-300 / SAS
Qty: 1
Type: Storage
Connector Location: External
Connector Type: 4x InfiniBand (SFF-8470)
Interface Required
Type: None
Miscellaneous
Compliant Standards: AS/NZS 3548 , EMC , EN 60950 , EN55022 , EN55024 , FCC CFR47 , FCC Class B certified , ICES-003
Included Accessories (CG): Low-profile bracket
Microsoft Certification: Compatible with Windows 7
MTBF: 200,000 hour(s)
Product Type (CG): Storage controller (RAID)
Power Device
Type: None
Service
Support Details Full Contract Period: 3 years
Support Details Service Included: Parts and labor
Support Details Type: Limited warranty
Slot Provided
Type: None
Slot Required
Total Qty: 1
Type: PCI Express x8
Software
Type: Drivers & Utilities
Storage Controller
Channel Qty: 8
Controller Interface Type: Serial ATA-300 / SAS
Data Transfer Rate: 300 MBps
Form Factor: Plug-in card
Interface Type: PCI Express x8
Low Profile: Low profile
Max Storage Devices Qty: 122
RAID Level: RAID 0 , RAID 1 , RAID 10E , RAID 1E
Supported Devices: Disk array (RAID) , Hard drive
System Requirements
Min Operating System: Microsoft Windows 2000 , Microsoft Windows Server 2003 , Microsoft Windows Server 2003 x64 Edition , Microsoft Windows XP , Novell NetWare 5.1 , Novell NetWare 6.5 , Red Hat Enterprise Linux 3 , SunSoft Solaris 2.6 - 2.10 , SuSe Linux , SuSE Linux Enterprise Server
Service & Support
Type: 3 years warranty
