All Categories  > Cables  > Cable Connectors/Terminators  > StarTech.com 4 Port VGA Video Extender over Cat 5
StarTech.com 4 Port VGA Video Extender over Cat 5 View Photo Gallery

StarTech.com 4 Port VGA Video Extender over Cat 5

Mfg. Part: ST1214T  |  CDW Part: 1303362  |  UNSPSC: 43201614
Log On to Email this Page or
Add to Favorites.




Video extender - 4 ports - external - up to 490 ft
Main Features
Qty
$149.99
Advertised Price
Availability:
Availability
Call for availability.
Call
Product Overview
Technical Specs
Accessories

Compatible Accessories for StarTech.com 4 Port VGA Video Extender over Cat 5

Product Overview Availability Advertised Price
StarTech.com VGA Video Extender Remote Receiver over Cat 5 - video extender
Video extender - external - up to 490 ft
Availability
Call for availability.
Call
$81.99
Qty
StarTech.com 6 ft Coax High Resolution VGA Monitor Extension Cable-HD15 M/F
SVGA High Density DB15 Male to High Density DB15 Female 6 foot coaxial cable with thumbscrews on both ends
Availability
In stock and ready for shipment. Ships same day if ordered before 4pm CT.
In Stock
$10.99
Qty
StarTech.com Coax VGA Monitor Extension Cable - VGA extender - 15 ft
VGA extender - HD-15 (M) - HD-15 (F) - 15 ft - molded
Availability
Call for availability.
Call
$21.99
Qty
Product Overview
Main Features
  • Video extender
  • 4 ports
  • external
  • up to 490 ft
"This 4 Port transmitter unit is designed for use with our ST121 VGA Video over Cat 5 extension series. This convenient video distribution system simplifies implementing digital signage solutions by allowing a single VGA source to be broadcast to multiple displays at up to 492 ft. (150m) away.

Comprised of a 4 port VGA extender unit (this device - ST1214T) or an 8 port VGA extender unit (ST1218T) and one ST121R Receiver Unit per display as necessary, the VGA and Audio extension series can transmit a single VGA output and corresponding audio to four or eight displays/receivers over standard Cat 5 UTP cable.

For even more versatility, the VGA over Cat 5 Repeater (ST121EXT) can be used to increase the total VGA extension distance by an additional 492 ft., allowing the VGA signal to be broadcast at a total distance of 984 ft. from transmitter to receiver. Similarly, up to three repeater units can be used between the transmitter and receiver units allowing monitors to be connected between the two units, while still extending the total distance between the transmitter and receiver units."
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Cable
Connectivity Left Connector Type: 15 pin HD D-Sub (HD-15)
Connectivity Right Connector Type: 15 pin HD D-Sub (HD-15)
Header
Compatibility: PC
Manufacturer: StarTech.com
Model: 4 Port VGA Video Extender over Cat 5
Packaged Quantity: 1
Product Line: StarTech.com
Interface Provided
Connector Type: 15 pin HD D-Sub (HD-15)
Gender: Male
Interface: VGA input
Qty: 1
Type: Display / video
Gender: Female
Interface: VGA output
Connector Type: RJ-45
Interface: Output
Qty: 4
Miscellaneous
Color: Black
Compliant Standards: CE , FCC
Networking
Connectivity Technology: Wired
Form Factor: External
Max Transfer Distance: 490 ft
Ports Qty: 4
Status Indicators: Active , Power
Type: Video extender
Power Device
Form Factor: External
Type: Power adapter
Service
Support Details Full Contract Period: 1 year
Support Details Type: Limited warranty
Slot Provided
Type: None
Slot Required
Type: None
KVM
KVM Max Supported Video Resolution: 1024 x 768
Service & Support
Type: 1 year warranty
