Symbol LS4278 - barcode scanner

Mfg. Part: LS4278-SR20007ZZWR|CDW Part: 1198509|UNSPSC: 43211701
  • Barcode scanner
  • portable
  • decoded
  • Bluetooth
Availability:3-5 days
Orders placed today will ship within 5 days
CallCall


This item was discontinued on August 15, 2012.

Sales Assistance

800.800.4239 Mon-Fri 7am-7:30pm CT

Answer within 24 hours.



Untitled Document
Close

Have leasing questions? Let us know how can we help.

Note: Leasing is available to businesses only. Leasing is not available to individuals.
800.800.4239
Mon-Fri 7am-7:30pm CT
Product Overview
Main Features
  • Barcode scanner
  • portable
  • decoded
  • Bluetooth
Symbol's cordless LS4278 provides superior bar code scanning in a durable future-proof device that delivers an outstanding total cost of ownership. Workers can move within a 50 ft./15 m radius to scan items - and the elimination of hazardous cables creates a safer work environment. From cashiers moving around the register to scan large, heavy items and check for missed items to healthcare workers double checking that the right patient is receiving the right medication, integrated Bluetooth wireless personal area networking (WPAN) provides reliable and secure wireless transmission of data between the scanner and your host. Productivity is improved, revenues are protected and potential liability due to injury from lifting heavy objects is reduced.

The LS4278 is designed to deliver exceptional scanning performance. Users can scan objects at any angle - the innovative multi-line rastering scan pattern eliminates the need for exact aim and positioning of the scanner. The laser line moves vertically during scanning, allowing accurate capture of even the smallest, stacked and poorly printed bar codes on the first scan. And with superior motion tolerance, users no longer need pause between scans, further increasing productivity.

The LS4278 scanner is designed to withstand all day every day use, from drops to spills, with features that deliver maximum uptime and investment protection. The scanner's patented single board construction eliminates the most common point of failure - the interconnection between multiple boards. Even if the scanner is accidentally dropped, a five-foot (1.5m) drop specification ensures continuous reliable operation. The scanner offer industrial charging contacts that eliminate wear when cradling the device, providing a reliable charging connection through hundreds of thousands of insertions - other common charging techniques show wear between 5, 000 to 10, 000 insertions. Drain points are designed into the protect sensitive internal electronics from accidental liquid spills. Built-in enterprise durability delivers a low total cost of ownership.
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Barcode
Barcodes: Codabar , Code 128 , Code 128 Full ASCII , Code 39 , Code 39 Full ASCII , Code 39 Trioptic , Code 93 , Discrete 2 of 5 , EAN/JAN , GS1 DataBar , Interleaved 2 of 5 , MSI-Plessey , UCC/EAN-128 , UPC
Features: Reduced Space Symbology (RSS)
Light Source Wave Length: 650 nm
Pitch (Degrees): 60
Print Contrast Signal (PCS): 25%
Skew (Degrees): 60

Battery
Form Factor: AAA type
Installed Qty: 3
Technology: Nickel metal hydride

Environmental Parameters
Drop Specification: 5 ft to concrete
Humidity Range Operating: 5 - 95%
Max Operating Temperature: 122 °F
Min Operating Temperature: 32 °F

Header
Compatibility: PC
Manufacturer: Symbol Technologies
Model: LS4278
Packaged Quantity: 1
Product Line: Symbol

Input Device
Connectivity Technology: Wireless
Interface Type: Bluetooth
TTL Decoding: Decoded

Miscellaneous
Color: Twilight black
Compliant Standards: CSA C22.2 No. 60950-00 , EMC , EN 60950 , FCC Part 15 B , ICES-003 , IEC950 , RoHS , UL 1950

Power Device
Type: None

Scanner
Form Factor: Portable
Scan Element Type: Visible laser diode
Scan Mode: Single-pass
Type: Barcode scanner

Service
Support Details Full Contract Period: 3 years
Support Details Type: Limited warranty

Slot Required
Type: None

Dimensions & Weight
Depth: 2.7 in
Height: 3.8 in
Weight: 8.4 oz
Width: 7.3 in

Service & Support
Type: 3 years warranty
