Patton DialFire 2960/16 RAS - remote access server

Mfg. Part: 2960/16B/RUI|CDW Part: 2716596|UNSPSC: 43222625
Patton DialFire 2960/16 RAS - remote access server
  • Remote access server
  • Ethernet
  • ISDN
  • Fast Ethernet
  • HDLC
  • Frame Relay
  • PPP DSU/CSU
  • 16 digital port(s)
  • 1U
  • rack-mountable
Availability:Call
Call for availability
CallCall


This item was discontinued on March 6, 2013.

Sales Assistance

800.800.4239 Mon-Fri 7am-7:30pm CT

Answer within 24 hours.



Untitled Document
Close

Have leasing questions? Let us know how can we help.

Note: Leasing is available to businesses only. Leasing is not available to individuals.
800.800.4239
Mon-Fri 7am-7:30pm CT
Product Overview
Main Features
  • Remote access server
  • Ethernet
  • ISDN
  • Fast Ethernet
  • HDLC
  • Frame Relay
  • PPP DSU/CSU
  • 16 digital port(s)
  • 1U
  • rack-mountable
The Patton DialFire 2960 RAS is an ideal solution for the established Internet Service Provider (ISP) that is expanding into a calling area. By integrating capabilities into the 2960 Remote Access Server, the ISP lowers expansion costs and produces revenue immediately.

Load-sharing dual-redundant power supplies and integrated Web-based SNMP/HTTP management system capabilities make the 2960 RAS the most reliable and easiest to use RAS in the business!

Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Battery
Type: None

Bay Provided
Type: None

Cabinet
Chassis Built-in Devices: LED panel

Cable
Connectivity Details Length: 10 ft
Connectivity Details Type: Serial cable



Connectivity Details Type: Network cable

Environmental Parameters
Humidity Range Operating: 5 - 95%
Max Operating Temperature: 104 °F
Min Operating Temperature: 32 °F

Header
Compatibility: PC
Manufacturer: Patton Electronics
Model: 2960/16 RAS
Packaged Quantity: 1
Product Line: Patton DialFire

Interface Provided
Connector Type: RJ-45
Interface: Ethernet 10Base-T/100Base-TX
Qty: 1
Type: Network



Connector Type: RJ-48C
Interface: T1/E1
Qty: 4
WAN DMZ: WAN



Interface: RS-232
Type: Management

Line Properties
Line Rate: T-1/E-1

Miscellaneous
Authentication Method: CHAP , Internal user database , PAP , RADIUS
Compliant Standards: CS-03 , EMC , EN 60950 , FCC Part 15 A , FCC Part 15 B , FCC Part 68 , UL 1950
Height (Rack Units): 1
Rack Mounting Kit: Included

Modem
Data Compression Protocol: ITU V.42bis
Digital Ports Qty: 16
Enclosure Type: Integrated
Protocols & Specifications: Bell 103 , Bell 202 , Bell 212A , ITU V.110 (I.463) , ITU V.21 , ITU V.22 , ITU V.22bis , ITU V.23 , ITU V.32 , ITU V.32bis , ITU V.34 , ITU V.8 , ITU V.8bis , ITU V.90 , ITU V.92 , k56Flex
Type: DSU/CSU

Networking
Compliant Standards: IEEE 802.3
Connectivity Technology: Wired
Data Link Protocol: Ethernet , Fast Ethernet , Frame Relay , HDLC , ISDN , PPP
Data Transfer Rate: 100 Mbps
Features: ARP support , Firmware upgradable , IP address filtering , Packet filtering , RARP support , Syslog support , Trivial File Transfer Protocol (TFTP) support
Form Factor: Rack-mountable
Network Transport Protocol: ICMP/IP , SLIP , TCP/IP
Remote Management Protocol: HTTP , SNMP , Telnet
Type: Remote access server

Processor
Clock Speed: 100 MHz
Manufacturer: Intel
Type: 80960VH

Service
Support Details Full Contract Period: 1 year
Support Details Type: Limited warranty

Slot Provided
Free Qty: 1
Total Qty: 1
Type: PMC

Cable Details
Included Qty: 1



Included Qty: 3

Dimensions & Weight
Depth: 11.8 in
Height: 1.7 in
Weight: 44.3 lbs
Width: 16.9 in

Flash Memory
Installed Size: 4 MB

Hard Drive
Type: None.

Power Device
Form Factor: Internal
Frequency Required: 50/60 Hz
Installed Qty: 2
Max Supported Qty: 2
Nominal Voltage: AC 120/230 V
Power Consumption Operational: 35 Watt
Type: Power supply - redundant

RAM
Installed Size: 32 MB
Technology: EDO RAM
