All Categories  > Monitors & Projectors  > Medical Displays  > Dome by NDSsi E4c, 4MP Color, 30-inch, No VC, Monitor
Dome by NDSsi E4c, 4MP Color, 30-inch, No VC, Monitor View Photo Gallery
Untitled Document
Close

Having leasing questions? Let us know how can we help.
800.800.4239 Mon-Fri 7am-7:30pm CT
Leasing FAQs

Dome by NDSsi E4c, 4MP Color, 30-inch, No VC, Monitor

Mfg. Part: 997-4157-00  |  CDW Part: 1504917  |  UNSPSC: 43211902

This product was discontinued as of Thursday, January 12, 2012. Call for availability.
LCD display - 4MP - color - TFT - 30" - widescreen - 2560 x 1600 - 300 cd/m2 - 700:1 - 14 ms - 0.25 mm - DVI-D
Main Features





Product Overview
Technical Specs
Warranties and Services
Product Overview
Main Features
  • LCD display
  • 4MP
  • color
  • TFT
  • 30"
  • widescreen
  • 2560 x 1600
  • 300 cd/m2
  • 700:1
  • 14 ms
  • 0.25 mm
  • DVI-D
The Dome E4c is a 4-megapixel color, 30-inch, color display for diagnostic viewing, with 300 cd/m² brightness, 700:1 contrast, DICOM calibration, Dual Channel DVI (Dual Link) and a 5-year standard warranty "Dome E4c is a bezel-less diagnostic display that is FDA 510(k) cleared, medically certified, and can be used throughout the healthcare enterprise. The wide-screen, 16:10 format of the Dome E4c simplifies comparison studies by eliminating image split caused by the bezel of a dual-head monitor and by offering more screen space to show multiple images. With 4MP resolution, the Dome E4c displays more than 90% of a CR image without scaling. With the ability to show 15 full size 512 x 512 images at the same time, E4c dramatically increases productivity when viewing large datasets and studies with multiple series.
Features:
• 5-year Standard Warranty
• 4-megapixel color
• 30-inch wide-screen
• High-bright display for diagnostic viewing
• 16.7 million colors
• DICOM calibration
• Dual Channel DVI (Dual Link)
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Chassis
Built-in USB Hub: Yes
Medical Display
Resolution: 4MP
Type: Color
Service & Support
Type: 5 years warranty
Display
Color Support: 16.7 million colors , 24-bit (16.7 million colors)
Diagonal Size (metric): 76.2 cm
Form Factor: Desktop
Horizontal Viewing Angle: +85 / -85
Image Aspect Ratio: 16:10
Input Signal: DVI-D
Pixel Pitch: 0.25 mm
Projector Image Brightness: 300 cd/m2
Projector Monitor Features: DICOM calibrated , RightLight
Response Time: 14 ms
Technology: TFT active matrix
Type: LCD display
Vertical Viewing Angle: +85 / -85
Widescreen: Widescreen
Audio Output
Type: None
Dimensions & Weight
Depth: 2.8 in
Height: 18.6 in
Weight: 28 lbs
Width: 28.1 in
Display (Projector)
Diagonal Size: 30 in
Image Contrast Ratio: 700:1
Interface: DVI
Max Resolution: 2560 x 1600
Environmental Parameters
Max Operating Temperature: 95 °F
Min Operating Temperature: 50 °F
Header
Compatibility: PC
Manufacturer: NDS Surgical Imaging
Model: E4C
Packaged Quantity: 1
Product Line: DOME
Input Device
Type: None
Interface Provided
Interface (Output): USB downstream
Qty: 2
Interface (Output): USB upstream
Qty: 1
Connector Type: 24 pin digital DVI
Interface (Output): DVI-D (dual link)
Miscellaneous
Compliant Standards: CCC , CE , DDC-2B , DIN 6868-57 , EN 60601-1-2 , FCC , FDA 510k , KCC , RoHS , VCCI , VESA EDID
Flat Panel Mount Interface: 100 x 100 mm , 100 x 200 mm
Networking
Type: None
Power Device
Form Factor: Internal
Frequency Required: 50 - 60 Hz
Nominal Voltage: AC 120/230 V
Service
Support Details Full Contract Period: 5 years
Support Details Type: Limited warranty
Video Input
TV Tuner Presence: No
