All Categories  > Networking Products  > Application Delivery Controllers  > Blue Coat PacketShaper 3500 - network monitoring device
Blue Coat PacketShaper 3500 - network monitoring device
Untitled Document
Close

Have leasing questions? Let us know how can we help.

Note: Leasing is available to businesses only. Leasing is not available to individuals.
800.800.4239
Mon-Fri 7am-7:30pm CT
Leasing FAQs

Blue Coat PacketShaper 3500 - network monitoring device

Mfg. Part: PS3500-L010M-1024   |  CDW Part: 1643198  |  UNSPSC: 43222634

This product was discontinued as of Friday, November 09, 2012. Call for availability.
Network monitoring device - 0 / 2 - Ethernet, Fast Ethernet, Gigabit Ethernet - 2U - rack-mountable
Main Features





Product Overview
Technical Specs
Accessories
Warranties and Services
Product Overview
Main Features
  • Network monitoring device
  • 0 / 2
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
  • 2U
  • rack-mountable
Designed for the branch office or the enterprise core, the PacketShaper 3500 has increased processor and memory scalability to accommodate future features and functional enhancements.
Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Chassis
Installed Devices Modules Qty: 0
Supported Devices Modules Qty: 2
Flash Memory
Type: None
Optical Storage
Type: None
Performance
Type: Shaping Link Size
Value: 10 Mbps
Battery
Type: None
Bay Provided
Type: None
Cabinet
Chassis Built-in Devices: Status LCD
Capacity
Type: Static partitions
Value: 256
Type: Classes
Value: 1024
Type: Dynamic partitions
Type: Shaping policies
Value: 512
Type: Maximum number of matching rules
Value: 2562
Type: IP hosts
Value: 20000
Type: Active tunnels
Value: 30
Header
Compatibility: PC
Manufacturer: Packeteer
Model: 3500
Packaged Quantity: 1
Product Line: Blue Coat PacketShaper
Interface Provided
Connector Type: RJ-45
Interface: Ethernet 10Base-T/100Base-TX/1000Base-T
Qty: 2
Type: Network
Connector Type: 9 pin D-Sub (DB-9)
Interface: RS-232
Qty: 1
Type: Management
Miscellaneous
Compliant Standards: AS/NZ 3548 Class A , CSA C22.2 , CSA C22.2 No. 60950-00 , EMC , EN 60950 , EN 61000-3-2 , EN 61000-3-3 , EN55022 Class A , EN55024 , FCC Class A certified , FCC Class B certified , FCC Part 15 , GOST , ICES-003 Class A , IEC 60950 , UL 1950 , VCCI Class A ITE
Height (Rack Units): 2
Modem
Type: None
Networking
Connectivity Technology: Wired
Data Link Protocol: Ethernet , Fast Ethernet , Gigabit Ethernet
Features: Traffic shaping
Form Factor: Rack-mountable
Network Transport Protocol: TCP/IP
Remote Management Protocol: HTTP , SNMP , Telnet
Type: Network monitoring device
Power Device
Form Factor: Internal
Frequency Required: 50/60 Hz
Nominal Voltage: AC 120/230 V
Type: Power supply
Slot Provided
Free Qty: 2
Total Qty: 2
Type: Expansion slot
Storage Floppy Drive
Type: None
Storage Removable
Type: None
Dimensions & Weight
Depth: 16 in
Height: 3.5 in
Weight: 18.1 lbs
Width: 17.4 in
