Aruba Instant IAP-105 - wireless access point

Mfg. Part: IAP-105-US   |  CDW Part: 2579016  |  UNSPSC: 43222631

Wireless access point - 802.11 a/b/g/n
Main Features






Availability:
Availability
Orders placed today will ship within 3 days.
1-3 days

$549.99Advertised Price

Lease Option ($17.16 /month) Lease Availability
Product Overview
Main Features
  • Wireless access point
  • 802.11 a/b/g/n
Multifunctional and affordable wireless access point (AP) delivers enterprise-grade Wi-Fi to high-density client environments in offices, hospitals, schools, retail stores and warehouses. The IAP-105 features two dual-band 2.4-GHz and 5-GHz radios with 2×2 MIMO and four integrated omni-directional downtilt antennas, making it ideal for warehouses and high-ceiling deployments.

Technical Specifications
Specifications are provided by the manufacturer. Refer to the manufacturer for an explanation of the print speed and other ratings.
Networking
Compliant Standards: IEEE 802.11a , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n , Wi-Fi CERTIFIED
Connectivity Technology: Wireless
Data Link Protocol: IEEE 802.11a , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n
Data Transfer Rate: 300 Mbps
Features: Adaptive Radio Management (ARM) , Auto-uplink (auto MDI/MDI-X) , Dual-band 802.11n , Maximum Ratio Combining (MRC) , MIMO technology , Power over Ethernet (PoE) , Trusted Platform Module (TPM)
Form Factor: External
Power Over Ethernet (PoE): PoE
Spread Spectrum Method: DSSS , OFDM
Type: Wireless access point
Wi-Fi Bands: 2.4 GHz , 5 GHz
Wireless Protocol: 802.11 a/b/g/n

Interface Provided
Connector Type: RJ-45
Interface: Ethernet 10Base-T/100Base-TX/1000Base-T
Qty: 1
Type: Network



Interface: Console
Type: Management

Miscellaneous
Compliant Standards: ANATEL , CB , CCC , cTUVus , EN 300.328 , EN 301.489.1 , EN 301.893 , EN 60950 , FCC , IEC 60950 , KCC , MIC , NOM , R&TTE , UL 2043 , UL 60950 , VCCI

Antenna
Antenna Form Factor (F): Internal integrated
Antenna Qty: 4
Directivity: Omni-directional

Service
Support Details Full Contract Period: Lifetime
Support Details Type: Limited warranty

Environmental Parameters
Humidity Range Operating: 5 - 95% (non-condensing)
Max Operating Temperature: 122 °F
Min Operating Temperature: 32 °F

Header
Compatibility: Mac , PC
Country Kits: United States
Manufacturer: Aruba
Model: IAP-105
Packaged Quantity: 1
Product Line: Aruba Instant

Line Properties
Line Coding Format: 16 QAM , 64 QAM , BPSK , CCK , QPSK

Dimensions & Weight
Depth: 5.3 in
Height: 1.8 in
Weight: 10.6 oz
Width: 5.2 in

Service & Support
Type: Limited lifetime warranty

Product Reviews
Aruba Instant IAP-105 - wireless access point 4.2 5 5 5
excellent product This is an excellent WAP for mid size offices. It is very easy to configure. The 'Mesh' feature that allows up to 16 devices to be controlled from a single interface is a real time saver. The multi SSID feature works great.We have deployed these units at several of our client locations and have not had any issues with them. June 13, 2013
Performs like a champ We have about a dozen deployed and think they are rock solid for a controller-less solution. Aruba regularly updates the code; adding more features. There are still a few features we miss from a controller based deployment, specifically guest account expiration and global upgrades, but we always have the option of using the controller too if needed. Excellent performance, multi-featured, on the bleeding edge of the wireless spec.I felt compelled to review this after someone here reviewed as if it was a consumer device, calling it hard to deploy. It does not get much easier than this. November 13, 2012
Easy to configure and very reliable We have many of these access points in 3 different buildings. They work great together and have excellent rage and great security. I highly recommend this product! October 19, 2012
Far too complicated for what it's supposed to do. When working on setting up a pair of Aruba AP-105's with the Aruba AirWave software, you'll find you need a separate DHCP Server, a separate VLAN, you'll have to go into the AP-105's Web Config and set them up in there - BEFORE you can even begin to even think about using the AirWave management software.These appear to be way more complex to set up than is necessary. August 14, 2012
Once the first one is setup (which, in itself, is a very easy process), programming quickly is sent to any new ones that are connected. Web interface is a snap. Security settings are well-handled. Dual radios -- 2.4 and 5.0. Range is good, and ARM handles the shifting of channels quickly and appropriately.Also sold under the Dell brand. November 18, 2011
